ConDim – New Version 8.1

2. February 2021

After the successful release of ConDim 8 in July 2020, we used the last few months to incorporate individual optimizations and improvements to make ConDim even more user-friendly. In addition, the following customer requests have already been implemented in ConDim 8.1:

General

Improved display of texts in the printout log
Revised and supplemented manual
Improved presettings of individual variables and input limits

Main window

Output of the column reinforcement level in the result graphic

Punching module

Possibility to set the manual handle distribution to zero
Output of additional variables in the detailed results

Punching foundation module

Iterative determination of the critical perimeter when entering soil pressures
Graphic representation of the iteration result

Shear joint module

Infographic plate / bar
Revised reinforcement selection
Calculation with dynamic loads possible

The update from ConDim 8.0 to 8.1 is made available to all existing ConDim 8 customers free of charge as a service. For more information go to www.condim.at
